UDOO – Quad Core Computer and powerful dedicated ARM for the GPIO

Yayy! Received my UDOO board today and it was total surprise. After so many weeks only today I had time to blog about the backed projects in Kickstater and I receive my first backed project delivery today 😉


Kickstarter InfoUDOO is a very powerful board based on dual or quad core ARM cortex-A9 CPU with great performance both on Android and Linux OS, and a dedicated ARM processor for the GPIO. These are the main specifications:

  • Freescale i.MX 6 ARM Cortex-A9 CPU Dual/Quad core 1GHz
  • Integrated graphics, each processor provides 3 separated accelerators for 2D, OpenGL® ES2.0 3D and OpenVG™
  • Atmel SAM3X8E ARM Cortex-M3 CPU (same as Arduino Due)
  • RAM DDR3 1GB
  • 76 fully available GPIO
  • Arduino-compatible R3 1.0 pinout
  • HDMI and LVDS + Touch (I2C signals)
  • Ethernet RJ45 (10/100/1000 MBit)
  • WiFi Module
  • Mini USB and Mini USB OTG
  • USB type A (x2) and USB connector (requires a specific wire)
  • Analog Audio and Mic
  • SATA (Only Quad-Core version)
  • Camera connection
  • Micro SD (boot device)
  • Power Supply 12V and External Battery connector

I has the UDOO now and will post more details and benchmarks soon 😉
